CPU
Intel® 6th/7th Generation Core™ i7/Core™i5/Core™i3/Pentium®/Celeron® series processor.
Single Socket H4 (LGA 1151) supported, CPU TDP support Up to 65W TDP
System Memory
Memory Capacity
Up to 64GB Unbuffered non-ECC UDIMM, DDR4-2400MHz, in 4 DIMM slots
Memory Type
2400MHz/2133MHz DDR4 288-pin Non-ECC UDIMM
DIMM Sizes
4GB, 8GB, 16GB
Memory Voltage
1.2V
On-Board Devices
Chipset
Intel® Q270 Express
SATA
Intel® Q270 Express controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Network Controllers
Single LAN with Intel® PHY I219LM LAN controller
Audio
ALC 1150 HD Audio
Graphics
Up to DP 1.2, up to HDMI 1.4b
Input / Output
LAN
1 RJ45 Gigabit Ethernet LAN ports
USB
4 USB 2.0 ports (2 rear + 2 via header(s)),
6 USB 3.0 ports (4 rear + 2 via header(s))
Video Output
1 HDMI port(s), 1 DP (DisplayPort) port(s), 1 DVI - D port(s)
Serial Port / Header
1 COM Port (1 header(s))
TPM
1 TPM Header
Expansion Slots
PCI-E
1 PCI-E 3.0 x16,
1 PCI-E 3.0 x4,
1 PCI-E 3.0 x1
M.2
Interface: PCIe 3.0 x4
Form Factor: 2280
System BIOS
BIOS Type
128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features
ACPI 5.0
SMBIOS 2.7
USB Keyboard support
Management
Software
SuperDoctor® 5, vPro, Watchdog
Power Configurations
ATX Power connector
ACPI Power Management
CPU thermal trip support for processor protection
Power-on mode for AC power recovery
Keyboard Wakeup from Soft-Off
PC Health Monitoring
Voltage
+12V, +3.3V, +5V, 1.05 (PCH), 1.2V (VDIMM), 3 -fan status, 3+2 Phase-switching voltage regulator, 3.3V standby, Chassis intrusion header, Supports system management utility, VBAT
FAN
3x 4-pin fan headers (up to 3 fans), 3 fans with tachometer monitoring, Low noise fan speed control, PWM fan speed control, Status monitoring for speed control
Temperature
CPU thermal trip support
LED
Suspend static indicator LED
Other Features
ACPI power management, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, Control of power-on for recovery from AC power loss, RoHS
